AC001 Charger – Belectriq

Make in India Icon

Designed & Manufactured in India with ~60% DVA (Domestic Value Addition)

Battery Backup Icon

Anti-Theft Mounting

Ethernet Wifi 4G Icon

Ethernet | Wifi | 4G

Safety Protections Icon

Highest safety features in the industry compliant with global standards

High Speed Charging Icon

OCPP | RFID | QR Code

High Efficiency Icon

LEDs to indicate charging modes

Battery Backup Icon

Battery Backup | RFID

Cable Management Icon

Boasts IP55 water & dust protection

Cable Management Icon

Self-healing with smart Auto-Recovery from faulted stage

Make in India Icon

Overvoltage Protection

Battery Backup Icon

Relay Welding Protection

High Speed Charging Icon

Over Current Protection

Safety Protections Icon

Onboard GFCI Protection

High Efficiency Icon

Varistor Fault Detection

Temperature Sensor Icon

Type B Earth Leakage Protection

Upgrade Power Rating Icon

Surge Protection upto 8kV

Ethernet Wifi 4G Icon

Over Temperature Protection

Technical Specifications

	Characteristic	AC Charger - Single Socket	AC Charger - Triple Sockets
Power	Rated Power	3.3 kW	10 kW
	Input voltage	180-265Vac, 1 phase (L-N-PE), 50±1Hz	310 - 460Vac, 3 phase (L-N-PE), 50±1Hz
	Number of Output	1	3
	Output current	0-16A	0-16A per output
	Output Charging Outlet	1 x 3.3kW (IEC 60309 / Domestic Socket)	3 x 3.3kW (IEC 60309 / Domestic Socket)
	Output voltage	230Vac	230Vac
	Battery Backup	Optional	Battery Backup for controlling unit > 60 mins

Controls and User Interface	Display	Optional	4.3°HMI LCD Display Touchscreen (Faults / Charging status/ Supply/ Connectivity status)
	LEDs	LEDs for charging/fault modes
	User Authentication	RFID + OCPPv1.6

Environment	Ambient emperature	-20°C to 55°C
	Storage Temperature	-20°C to 85°C
	Altitude	<2000 Mtr
	Humidity	<95%, Non condensing

Communication	External	WiFi, LAN / 4G (with signal boosting Antenna), OCPPv1.6
	Metering and Billing	Class 1 Energy Metering
	Charging Operation	RFID Card / QR Code / Mobile CMS App (OCPPv1.6)

Protection/Safety	Input/ Output protection	Over/Under voltage protection, Overload protection, Short circuit protection, Current leakage protection Grounding protection, Surge protection, Over temperature, Relay welding protection & Reverse polarity protection
	Mechanical Protection	Enclosure Mechanical Strength IK-08, IP55 for Outdoor use, Flame Retardant Grade UL94 V-0, Anti-Theft Mounting Design, Safety Lock
	Mounting	Wall / Pole Mount (Anti-Theft Design)
	Push Button	Mushroom Push Button for Emergency Stop
	Cooling	Natural Cooling

Certification	As per	Bharat EV AC Charger (BEVC-AC001) Specifications, AIS 138-Part 1
	Certification	IEC 61851 / AIS 138 Part-1 / IS-17017
