AC Type2 Charger – Belectriq

Make in India Icon

Designed & Manufactured in India with ~60% DVA (Domestic Value Addition)

Ethernet Wifi 4G Icon

Ethernet | Wifi | 4G

High Speed Charging Icon

OCPP | RFID | QR Code

Battery Backup Icon

Anti-Theft Mounting

Battery Backup Icon

Battery Backup | RFID

Safety Protections Icon

Highest safety features in the industry compliant with global standards

Cable Management Icon

Boasts IP55 water & dust protection

High Efficiency Icon

LEDs to indicate charging modes

Cable Management Icon

Temperature Sensor on Gun side (Optional)

Cable Management Icon

Self-healing with smart Auto-Recovery from faulted stage

Make in India Icon

Overvoltage Protection

Battery Backup Icon

Relay Welding Protection

High Speed Charging Icon

Over Current Protection

Safety Protections Icon

Onboard GFCI Protection

High Efficiency Icon

Varistor Fault Detection

Temperature Sensor Icon

Type B Earth Leakage Protection

Upgrade Power Rating Icon

Surge Protection upto 8kV

Ethernet Wifi 4G Icon

Over Temperature Protection

Technical Specifications

	Characteristic	AC Type2 Charger
Power	Rated Power	3.3 kW	7.4 kW	7.4 kW	11 kW	22 kW
	Input voltage	180-265Vac, 1 phase (L-N-PE), 50±1Hz	180-265Vac, 1 phase (L-N-PE), 50±1Hz	310 - 460Vac, 3 phase (L-N-PE), 50±1Hz	310 - 460Vac, 3 phase (L-N-PE), 50±1Hz	310 - 460Vac, 3 phase (L-N-PE), 50±1Hz
	Number of Output	1	1	2	1 or 2	1 or 2
	Output current	0-16A	0-32A	0-32A per output	0-16A per phase	0-32A per phase
	Output Charging Outlet	IEC62196 Type2
	Output voltage	230Vac	230Vac	230Vac per output	415Vac	415Vac
	Battery Backup	Battery Backup for controlling unit > 60 mins

Controls and User Interface	Display	Optional	Optional	4.3"HMI LCD Display	4.3"HMI LCD Display	4.3"HMI LCD Display
	LEDs	LEDs for charging/fault modes
	User Authentication	RFID + OCPPv1.6

Environment	Ambient emperature	-20°C to 55°C
	Storage Temperature	-40°C to 85°C
	Altitude	<2000 Mtr
	Humidity	<95%, Non condensing

Communication	External	WiFi, LAN / 4G (with signal boosting Antenna), OCPPv1.6
	Metering and Billing	Class 1 Energy Metering
	Charging Operation	RFID Card / QR Code / Mobile CMS App (OCPPv1.6)

Protection/Safety	Input/ Output protection	Over/Under voltage protection, Overload protection, Short circuit protection, Current leakage protection Grounding protection, Surge protection, Over temperature, Relay welding protection & Reverse polarity protection
	Mechanical Protection	Enclosure Mechanical Strength IK-08, IP55 for Outdoor use, Flame Retardant Grade UL94 V-0, Anti-Theft Mounting Design, Safety Lock
	Mounting	Wall / Pole Mount (Anti-Theft Design) - Floor Mount design available on request
	Charging Cable	High quality cable with Copper alloy & Silver-plated power contacts, Mating Cycles > 10,000 Temperature Sensor on Gun side (Optional)
	Push Button	Mushroom Push Button for Emergency Stop
Cooling	Natural Cooling

Certification	As per	IEC 61851 / AIS 138 Part-1 / IS-17017
	Certification	ARAI, CE
