150-1000V
Continuous Operation
20kW | 30kW
Efficiency >95%
Reactive Power Control
Micro Modular
CAN bus
High Power Charging
Made in India
| Parameters | Characteristic | ||||||
| Power | Input Connection | 3 Phase 4 Wire System | |||||
| Rate Voltage(V) | 415V±15% | ||||||
| Input Voltage Range(V) | 350V – 477V | ||||||
| Max Current (A) | 40A | 50A | ||||||
| Input Current Range(A) | 27A(477V) – 37A(350V) | ||||||
| Power Factor | 0.96 - 0.99 (50% to 100% Load) | ||||||
| THD(%) | <5%(50% to 100% Load) | ||||||
|
Controls and User Interface |
Output Voltage Range (V) | 200V to 1000V |
| Maximum Output Current (A) | 67A | 85A | |
| Voltage Accuracy (%) | ±0.5% | |
| Voltage Ripple (%) | 1% | |
| Current Accuracy (%) | ±1% | |
| Output Current Sharing (Parallel) | ±3% Imbalaance | |
| Efficiency (%) | ~ 95% ( 50% to 100% Load) | |
| External | CAN Bus |
| Protection/ Safety | Operating Temperature | -20°C to 55°C |
| Relative Humidity | <95% RH, Non-Condensing | |
| Altitude | ≤4000m Availability above 2000m with Power de-rating function. | |
| Dielectric Strength Input / Output | 2kV RMS | |
| Power Terminals to Chassis | 1.5kV RMS | |
| Ingress Protection | IP20 | |
| Input Protections | Overvoltage, Under Voltage , Overcurrent, Input Inrush current limiting, Built-in residual voltage discharge circuit | |
| Output Protections | Over-voltage, Over-Current and Short Circuit, Built-in residual voltage discharge circuit, Reverse feed Protection. | |
| Thermal Protection | Smart Thermal management with alarms | |
| Auto recovery | Input Under Voltage, Input Over-Voltage, Output Over- Voltage, Output Over-Current (3 times), Output Short Circuit | |
| Cooling Method | Forced Air Cooling with smart thermal management | |
| EMC | IEC 61000-6-1 and 6-3 | |
| Safety Standards | IEC-61851-1 and IEC-61851-23 |
